All State-space Analysis previous year questions

Practice every matching question in batches of 20, with every available option.

1
2009 · Electrical Engineering · Control Systems · State-space Analysis
Electrical Engineering (EE) 2009
The system transfer function is

Question diagram

Open complete paper
2
2009 · Electrical Engineering · Control Systems · State-space Analysis
Electrical Engineering (EE) 2009

The state-transition matrix of the above system is

Open complete paper
3
2010 · Electrical Engineering · Control Systems · State-space Analysis
Electrical Engineering (EE) 2010
The system \(\dot{x} = Ax + Bu\) with \(A = \begin{bmatrix} -1 & 2 \\ 0 & 2 \end{bmatrix}, \; B = \begin{bmatrix} 0 \\ 1 \end{bmatrix}\) is
Open complete paper
4
2012 · Electrical Engineering · Control Systems · State-space Analysis
Electrical Engineering (EE) 2012
The state variable description of an LTI system is given by (see image for state equations) where y is the output and u is the input. The system is controllable for
Open complete paper
5
2013 · Electrical Engineering · Control Systems · State-space Analysis
Electrical Engineering (EE) 2013 [Session 1]
The system is
Open complete paper
6
2013 · Electrical Engineering · Control Systems · State-space Analysis
Electrical Engineering (EE) 2013 [Session 2]
Common Data for Questions 48 and 49: The state variable formulation of a system is given as [x₁̇; x₂̇] = [-2, 0; 0, -1] [x₁; x₂] + [1; 1] u, x₁(0) = 0, x₂(0) = 0 and y = [1, 0] [x₁; x₂]. The system is
Open complete paper
7
2014 · Electrical Engineering · Control Systems · State-space Analysis
Electrical Engineering (EE) 2014 [Session 2]
The state transition matrix for the system \(\begin{bmatrix} \dot{x}_1 \\ \dot{x}_2 \end{bmatrix} = \begin{bmatrix} 1 & 0 \\ 1 & 1 \end{bmatrix} \begin{bmatrix} x_1 \\ x_2 \end{bmatrix} + \begin{bmatrix} 1 \\ 1 \end{bmatrix} u\) is
Open complete paper
8
2014 · Electrical Engineering · Control Systems · State-space Analysis
Electrical Engineering (EE) 2014 [Session 2]
The second order dynamic system \( \frac{dX}{dt} = PX + Qu \), \( y = RX \) has the matrices P, Q and R as follows: \( P = \begin{bmatrix} -1 & 1 \\ 0 & -3 \end{bmatrix} \), \( Q = \begin{bmatrix} 0 \\ 1 \end{bmatrix} \), \( R = \begin{bmatrix} 0 & 1 \end{bmatrix} \). The system has the following controllability and observability properties:
Open complete paper
9
2016 · Electrical Engineering · Control Systems · State-space Analysis
Electrical Engineering (EE) 2016 [Session 1]
Consider the following state-space representation of a linear time-invariant system.
\(\dot{\boldsymbol{x}}(t) = \begin{bmatrix} 1 & 0 \\ 0 & 2 \end{bmatrix} \boldsymbol{x}(t), \quad y(t) = \boldsymbol{c}^T \boldsymbol{x}(t), \quad \boldsymbol{c} = \begin{bmatrix} 1 \\ 1 \end{bmatrix} \text{ and } \boldsymbol{x}(0) = \begin{bmatrix} 1 \\ 1 \end{bmatrix}\)
The value of \(y(t)\) for \(t = \log_e 2\) is ________.
Open complete paper
10
2016 · Electrical Engineering · Control Systems · State-space Analysis
Electrical Engineering (EE) 2016 [Session 2]
Consider a linear time invariant system \(\dot{x} = Ax\), with initial condition \(x(0)\) at \(t = 0\). Suppose \(\alpha\) and \(\beta\) are eigenvectors of (2 x 2) matrix A corresponding to distinct eigenvalues \(\lambda_1\) and \(\lambda_2\) respectively. Then the response \(x(t)\) of the system due to initial condition \(x(0) = \alpha\) is
Open complete paper
11
2017 · Electrical Engineering · Control Systems · State-space Analysis
Electrical Engineering (EE) 2017 [Session 1]
The transfer function of the system Y(s)/U(s) whose state-space equations are given below is:
\[ \begin{bmatrix} \dot{x}_1(t) \\ \dot{x}_2(t) \end{bmatrix} = \begin{bmatrix} 1 & 2 \\ 2 & 0 \end{bmatrix} \begin{bmatrix} x_1(t) \\ x_2(t) \end{bmatrix} + \begin{bmatrix} 1 \\ 2 \end{bmatrix} u(t) \]
\[ y(t) = [1 \; 0] \begin{bmatrix} x_1(t) \\ x_2(t) \end{bmatrix} \]
Open complete paper
12
2017 · Electrical Engineering · Control Systems · State-space Analysis
Electrical Engineering (EE) 2017 [Session 2]
Consider the system described by the following state space representation \[\begin{bmatrix} \dot{x}_1(t) \\ \dot{x}_2(t) \end{bmatrix} = \begin{bmatrix} 0 & 1 \\ 0 & -2 \end{bmatrix} \begin{bmatrix} x_1(t) \\ x_2(t) \end{bmatrix} + \begin{bmatrix} 0 \\ 1 \end{bmatrix} u(t)\] \[y(t) = \begin{bmatrix} 1 & 0 \end{bmatrix} \begin{bmatrix} x_1(t) \\ x_2(t) \end{bmatrix}\] If \(u(t)\) is a unit step input and \(\begin{bmatrix} x_1(0) \\ x_2(0) \end{bmatrix} = \begin{bmatrix} 1 \\ 0 \end{bmatrix}\), the value of output \(y(t)\) at \(t = 1\) sec (rounded off to three decimal places) is __________.
Open complete paper
13
2018 · Electrical Engineering · Control Systems · State-space Analysis
Electrical Engineering (EE) 2018
Consider a system governed by the following equations \(\frac{dx_1(t)}{dt} = x_2(t) - x_1(t)\) \(\frac{dx_2(t)}{dt} = x_1(t) - x_2(t)\) The initial conditions are such that \(x_1(0) < x_2(0) < \infty\). Let \(x_{1f} = \lim_{t\to\infty} x_1(t)\) and \(x_{2f} = \lim_{t\to\infty} x_2(t)\). Which one of the following is true?
Open complete paper
14
2019 · Electrical Engineering · Control Systems · State-space Analysis
Electrical Engineering (EE) 2019
Consider a state-variable model of a system \(\begin{bmatrix} \dot{x}_1 \\ \dot{x}_2 \end{bmatrix} = \begin{bmatrix} 0 & 1 \\ -\alpha & -2\beta \end{bmatrix} \begin{bmatrix} x_1 \\ x_2 \end{bmatrix} + \begin{bmatrix} 0 \\ \alpha \end{bmatrix} r\) and \(y = \begin{bmatrix} 1 & 0 \end{bmatrix} \begin{bmatrix} x_1 \\ x_2 \end{bmatrix}\), where \(y\) is the output, and \(r\) is the input. The damping ratio \(\xi\) and the undamped natural frequency \(\omega_n\) (rad/sec) of the system are given by
Open complete paper
15
2021 · Electrical Engineering · Control Systems · State-space Analysis
Electrical Engineering (EE) 2021
The state space representation of a first-order system is given as $\dot{x} = -x + u$ $y = x$ where, $x$ is the state variable, $u$ is the control input and $y$ is the controlled output. Let $u = -Kx$ be the control law, where K is the controller gain. To place a closed-loop pole at -2, the value of K is ______.
Open complete paper
