Zero-dimensional or point defects - Classification and Structure of Materials - Engineering Sciences Previous Year Questions

1

2007 · Engineering Sciences · Classification and Structure of Materials · Zero-dimensional or point defects

Engineering Sciences (XE) 2007

The enthalpy of formation of vacancies in Cu is 120 kJ.mol^-1. The equilibrium fraction of vacant lattice sites in Cu at 1000 K would be

A

1.35 x 10^-8

B

5.39 x 10^-7

C

7.76 x 10^-6

D

2.58 x 10^-9

Open complete paper

2

2007 · Engineering Sciences · Classification and Structure of Materials · Zero-dimensional or point defects

Engineering Sciences (XE) 2007

Cd²⁺ doped NaCl crystal has higher conductivity at room temperature as compared to pure NaCl due to

A

lower activation energy for movement of cations

B

increase in the concentration of cation vacancies

C

introduction of holes in the crystal

D

increase in concentration of anion vacancies

Open complete paper

3

2008 · Engineering Sciences · Classification and Structure of Materials · Zero-dimensional or point defects

Engineering Sciences (XE) 2008

A Schottky defect in CaF₂ is comprised of

A

one Ca²⁺ vacancy and one F⁻ vacancy

B

one Ca²⁺ vacancy and one F⁻ interstitial

C

two Ca²⁺ vacancies and one F⁻ vacancy

D

one Ca²⁺ vacancy and two F⁻ vacancies

Open complete paper

4

2010 · Engineering Sciences · Classification and Structure of Materials · Zero-dimensional or point defects

Engineering Sciences (XE) 2010

A Frenkel defect is

A

A pair of cation and anion vacancy

B

A pair of cation interstitial and cation vacancy

C

A cation vacancy

D

An anion vacancy

Open complete paper

5

2012 · Engineering Sciences · Classification and Structure of Materials · Zero-dimensional or point defects

Engineering Sciences (XE) 2012

A Schottky defect in an ionic crystal is a stoichiometric defect of

A

Cation vacancy

B

Anion vacancy

C

Cation and anion vacancy

D

Cation and anion interstitial

Open complete paper

6

2014 · Engineering Sciences · Classification and Structure of Materials · Zero-dimensional or point defects

Engineering Sciences (XE) 2014

The equilibrium concentration of vacancies in a pure metal

A

increases exponentially with temperature

B

decreases exponentially with temperature

C

varies linearly with temperature

D

is independent of temperature

Open complete paper

7

2015 · Engineering Sciences · Classification and Structure of Materials · Zero-dimensional or point defects

Engineering Sciences (XE) 2015

Vacancies play an important role in

A

deformation twinning

B

self diffusion

C

strain hardening

D

cross-slip

Open complete paper

8

2017 · Engineering Sciences · Classification and Structure of Materials · Zero-dimensional or point defects

Engineering Sciences (XE) 2017

Which of the following is a Frenkel defect?

A

One Cl vacancy and one Na vacancy in NaCl

B

One Zn vacancy and one Zn interstitial in ZnO

C

K at the Na site in NaCl

D

None of the above

Open complete paper

9

2017 · Engineering Sciences · Classification and Structure of Materials · Zero-dimensional or point defects

Engineering Sciences (XE) 2017

If the energy of formation of vacancies in pure copper is 0.9 eV, the fraction of vacancies in pure copper at 27 °C will be ………..×10^-16 (Boltzmann’s constant is 8.62×10^-5 eV/K)

Check answer

Open complete paper

10

2019 · Engineering Sciences · Classification and Structure of Materials · Zero-dimensional or point defects

Engineering Sciences (XE) 2019

In NaCl, the substitution of a Na⁺ ion by a Ca²⁺ ion would most probably lead to

A

the formation of a Na⁺ vacancy

B

the creation of a Cl⁻ interstitial

C

the formation of a Cl⁻ vacancy

D

the formation of a Na⁺ and Cl⁻ vacancy pair

Open complete paper

11

2020 · Engineering Sciences · Classification and Structure of Materials · Zero-dimensional or point defects

Engineering Sciences (XE) 2020

The number of Schottky defects per mole of KCl at 300 °C under equilibrium condition will be:
Given:
Activation energy for the formation of Schottky defect = 250 kJ.mol^-1
Avogadro number = 6.023 × 10²³ mol^-1
Universal Gas Constant = 8.314 J.K^-1.mol^-1

A

1.21 × 10¹⁸

B

1.52 × 10¹⁶

C

9.75

D

2.42 × 10¹²

Open complete paper

12

2023 · Engineering Sciences · Classification and Structure of Materials · Zero-dimensional or point defects

Engineering Sciences (XE) 2023

Aliovalent doping of $MgCl_2$ in $NaCl$ leads to the formation of defects. Which one of the following is the correct defect reaction?

A

$Mg_{Cl}^{\bullet} + Na_{Na} + V_{Cl}^{'} = \emptyset$

B

$Mg_{Na}^{\bullet} + Cl_{Cl} + V_{Na}^{'} = \emptyset$

C

$Mg_{Na} + Cl_{Cl} = \emptyset$

D

$Mg_{Na}^{\bullet} + Cl_{Cl} + V_{Na}^{\bullet} = \emptyset$

Open complete paper

13

2024 · Engineering Sciences · Classification and Structure of Materials · Zero-dimensional or point defects

Engineering Sciences (XE) 2024

Which of the following figures schematically represent(s) either the Frenkel defect or the Schottky defect in ionic solids?

A

Figure (A): A 3x4 grid of alternating blue and orange circles with one orange circle missing from the middle row.

B

Figure (B): A 3x4 grid of alternating blue and orange circles with one orange circle displaced to an interstitial position in the middle row.

C

Figure (C): A 3x4 grid of alternating blue and orange circles with two orange circles missing from the middle row.

D

Figure (D): A 3x4 grid of alternating blue and orange circles with one orange circle missing from the middle row and another orange circle displaced to an interstitial position.

Check answer

Open complete paper

14

2026 · Engineering Sciences · Classification and Structure of Materials · Zero-dimensional or point defects

Engineering Sciences (XE) 2026

The equilibrium vacancy concentration in aluminum at 900 K is \(1.1 \times 10^{-4}\). The enthalpy of formation of vacancies, in kJ.mol\(^{-1}\), is __________ (rounded off to one decimal place).
Given: Universal gas constant = \(8.314 \text{ J.K}^{-1}.\text{mol}^{-1}\)

Check answer

Open complete paper

15

2026 · Engineering Sciences · Classification and Structure of Materials · Zero-dimensional or point defects

Engineering Sciences (XE) 2026

Which one of the following statements regarding point defects in ionic solids is correct?

A

Frenkel defects are dominant in those ionic solids where there is a considerable size difference between the cation and anion.

B

Schottky defects are dominant in those ionic solids where there is a considerable size difference between the cation and anion.

C

Schottky defects are the dominant defects in all ionic solids.

D

Similar density of both Frenkel and Schottky defects is present in all ionic solids.

Open complete paper
